CE marked
Main Features
The analyser is managed by an integrated touch screen panel PC by means of the dedicated software running in Windows® ambient.Bench top analysers with two test positions.Bath made in aluminium with integrated cooling system.
The cooling of the sample happens inside the dry cooling block.
The instruments is equipped with motor compressors with gas CFC free.
Dimensions
width: 34 cm
depth: 50 cm
height: 50 cm
Weight:
30 kg
Application
Determination of the Crystallization Point
Main characteristics
User friendly
Automatic Analyser for the determination of the Shukoff and Tempering curves
Determination of min T - max T
Automatic calculation of the slope (Q = ΔT/Δt)
Easy sample preparation: with glass bottles and / or disposable plastic cups
Rapidity in analysis execution
Excellent repeatability of the analysis
No particular maintenance required
Measuring devices
PT100 sensors class A
Measuring Parameters
Temperatures: in °C
Measuring range: +80 °C … –50 °C
Bath temperatures: –10 °C … +60 °C
Heating curve: 3°C/min
Cooling curve: 1°C/min
Software
User friendly
Main features
interfaceReal time display of all the analytical parameters
Independent managing of the two / six test positions
Storage of all the analysis
Storage of the results in Excel® format
Display of the graphic
Execution of recipes
Curves comparison
Printable results
Calibration
Automatic calibration of each temperature probe by means of the calibration decade box (Art. OilLab 80-T)
Storage of the data referred to the calibration
Last calibration date referred to each single probe displayed
Diagnostic
Access to all analogue and digital signals (inlet and outlet) in order to verify their functioning.
Accessories
Calibration decade box – PT100 simulator with cable and connector for Thermofat range (Art. OilLab 80-T)
Spare Parts
Thermo 206: PT100 sensor (color)
Thermo 220: Shukoff bottle 19/26
Thermo 221: Shukoff bottle 24/29
LT-1412: Teflon stopper 19/26 with hole for PT100 sensorLT-1422: Teflon stopper 24/29 with hole for PT100 sensor
Thermo Twin Thermo Four
